O330.RP-PDPVZ.72NV/0030_H006

Extended functional reserve capacities for maximum reliability
Baumer PinPoint LED: Small, homogeneous light spot with sharp edges
Fixed preset for the simplest commissioning
Quick mounting by means of M3 threaded bushes made of brass

Objednací číslo: 11728355
Výrobce: Baumer Electric AG

Dostupnost: na dotaz

+Přidat do nezávazné poptávky

Poradím vám

Ing. Jaroslav Dančák

Technik specialista pro průmyslové snímače
BAUMER

+420 733 533 400

jaroslav.dancak@ajptech.cz

Parametry

Nákresy

Diagramy

Ke stažení

Příslušenství

Podpora

Podobné produkty

Parametry

Základní parametry

Typ:	Retro-reflective sensor
Zdroj světla:	Pulsed PinPoint LED
Skutečný rozsah Sb:	5 m
jmenovitý rozsah:	6 m
Polarizační filtr:	Yes
Indikace znečištění:	Flashing output indicator
Výstupní indikátor:	LED yellow
Indikace napájení:	LED green
Vlnová délka:	634 nm
Potlačení vzájemného ovlivňování:	Yes
Odklon od osy:	< 1,5°

Elektrické parametry

Doba odezvy:	< 0.5 ms
Rozsah napájecího napětí +Vs:	10 - 30 VDC
Maximální spotřeba proudu (bez zátěže):	50 mA
Běžná spotřeba proudu:	25 mA
Pokles napětí Vd:	<2 VDC
Výstupní funkce:	Light / dark operate
Výstupní obvod:	PNP complementary
Výstupní proud:	100 mA
Ochrana proti zkratu:	Yes
Ochrana proti přepólování:	Yes

Mechanické parametry

Šířka \| průměr:	11 mm
Výška \| Délka:	32 mm
Hloubka:	21 mm
Konstrukce:	Rectangular
Mechanické upevnění:	Threaded sleeves M3 (brass)
Materiál pouzdra:	Plastic (ABS, ASA, PMMA)
Materiál krycího skla:	PMMA
Způsoby připojení:	Flylead connector PVC M8 4-pin, L=300 mm

Okolní podmínky

Pracovní teplota:	-25 - +55 °C
Třída krytí:	IP 67
Skladovací teplota:	-40 - +70 °C
