HEAG172 ST 65 LWL-Transmitter

For high interference locations
Converting standard square-wave signals into fiber-optic signals
Each channel is coupled onto fiber-optic easy-to-fit plug
3 different plug versions available
Delay time over a 100 m length of fiber-optic is 1 µs
Except of POF all fiber optic cable usable, e. g. PCF 200 μm, silica fiber 50 and 62.5 μm

Objednací číslo: 11054948
Výrobce: Baumer Electric AG

Dostupnost: na dotaz

Chcete znát dostupnost zboží? Vložte produkt do poptávky a my se vám ozveme.
Potřebujete poradit s výběrem nebo najít alternativu? Kontaktujte produktového specialistu.

+Přidat do nezávazné poptávky

Poradím vám

Ondřej Štěpánek

Produktový manažer
BAUMER

+420 733 101 651

ondrej.stepanek@ajptech.cz

Parametry

Nákresy

Ke stažení

Podpora

Podobné produkty

Parametry

Elektrické vlastnosti

Napájecí napětí:	9...26 VDC
Spotřeba:	≤200 mA
Vstupy:	4 x HTL
Vstupní signály:	K1, K2, K3, K4 + inverted
Výstup:	4 x fiber-optic
Výstupní signál:	Fiber-optic 1, 2, 3 and 4
Přenosová frekvence:	≤250 kHz
Přenosová vzdálenost:	≤300 m
Schválení:	CE

Mechanické provedení

Rozměry (Š x V x D):	122 x 122 x 80 mm
Ochrana EN 60529:	IP 65
Pracovní teplota:	-20...+70 °C (without dew)
Připojení:	3x cable gland M20x1.5 4x cable gland M16x1.5
