Kamery se základními funkcemi pro cenově výhodné aplikace

Kamery se základními funkcemi pro cenově výhodné aplikace



 Série EX

Filtrace
Rozlišení kamery
0.3 MP – 1 MP
(2/2)
> 1 – 2 MP
(2/2)
> 2 – 5 MP
(2/2)
> 8 – 20 MP
(2/2)
Zrušit
Snímkovací frekvence
1 … 10 fps
(2/2)
11 … 20 fps
(1/1)
31 … 40 fps
(1/1)
51 … 100 fps
(2/2)
201 … 300 fps
(2/2)
Zrušit
Datové rozhraní
Gigabit Ethernet
(7/7)
USB 3.0
(1/1)
Zrušit
Barevné modely
Mono
(4/4)
Raw Bayer
(4/4)
Zrušit
Senzor
onsemi MT9J003
(2/2)
onsemi MT9P031
(1/1)
onsemi PYTHON1300
(2/2)
onsemi PYTHON300
(2/2)
Sony IMX249 Gen1
(1/1)
Zrušit
Velikost pixelu
1.67 × 1.67 µm
(2/2)
2.2 × 2.2 µm
(1/1)
4.8 × 4.8 µm
(4/4)
5.86 × 5.86 µm
(1/1)
Zrušit
Senzor typ
1/1.2" CMOS
(1/1)
1/2.3″ CMOS
(2/2)
1/2.5″ CMOS
(1/1)
1/2″ CMOS
(2/2)
1/4″ CMOS
(2/2)
Zrušit
Ing. Jakub Sedlmajer
Ing. Jakub Sedlmajer
Produktový specialista pro průmyslové čtečky a kamerové systémy
BAUMER | IOSS
Ing. Jakub Sedlmajer - QR Kontakt
+420 739 087 013
jakub.sedlmajer@ajptech.cz
FotoProdukt (8)SenzorSenzor typSnímkovací frekvenceRozlišení senzoruSkladová dostupnost
VEXG-02Consemi PYTHON300
1/4″ CMOS
201 … 300 fps
640 × 480 px
na dotaz
VEXG-02Monsemi PYTHON300
1/4″ CMOS
201 … 300 fps
640 × 480 px
na dotaz
VEXG-100C.Ronsemi MT9J003
1/2.3″ CMOS
1 … 10 fps
3856 × 2764 px
na dotaz
VEXG-100M.Ronsemi MT9J003
1/2.3″ CMOS
1 … 10 fps
3856 × 2764 px
na dotaz
VEXG-13Consemi PYTHON1300
1/2″ CMOS
51 … 100 fps
1280 × 1024 px
na dotaz
VEXG-13Monsemi PYTHON1300
1/2″ CMOS
51 … 100 fps
1280 × 1024 px
na dotaz
VEXG-52M.Ronsemi MT9P031
1/2.5″ CMOS
11 … 20 fps
2592 × 1944 px
na dotaz
VEXU-24CSony IMX249 Gen1
1/1.2" CMOS
31 … 40 fps
1920 × 1200 px
na dotaz

Průmyslové kamery Baumer ze série EX disponují nejnovější generací snímačů CMOS s globální závěrkou s rozlišením až 10 megapixelů.

Umožňují přesnou a dlouhodobě stabilní analýzu obrazu. Robustní kovové pouzdro o rozměrech jen 29 x 29 mm s možností uchycení pomocí otvorů se závity M3 na každé straně. CS-mount usnadňuje kompatibilitu s cenově výhodnými objektivy a jednoduché konektorové připojení (4 piny M8), usnadňují integraci i v prostorově omezených podmínkách.
