OT330.DN-GLUBO.72N

2.5 m sensing range thanks to time of flight principle
Distance measurement via IO-Link or analog output
Reliable also on very dark and shiny objects
Manipulation-proof, simple teach-in via qTeach or line teach
Extended parameterization options and additional diagnostic data via IO-Link
Infrared laser light source suitable for use in dusty or smoky environments
Alignment Guide - visible, red light beam for aligning the infrared laser

Objednací číslo: 11731312
Výrobce: Baumer Electric AG

Dostupnost: na dotaz

+Přidat do nezávazné poptávky

Parametry

Nákresy

Diagramy

Ke stažení

Příslušenství

Podpora

Podobné produkty

Parametry

Základní parametry

Typ:	Distance measuring
Verze:	Time of Flight
Měřicí vzdálenost Sd:	0 - 2500 mm
Měřicí rozsah:	2500 mm
Nastavení:	Teach-in and IO-Link
Indikace napájení:	LED green
Výstupní indikátor:	LED yellow
Opakovatelnost:	≤ 2 - 1.5
Chyba linearity:	± 10 mm
Typ paprsku:	Point
Potlačení vzájemného ovlivňování:	Yes
Odklon od osy:	< 1,5°
Teplotní drift:	<0,3 mm/K: <750 mm <0,04 % Sde/K: >750 mm

Zdroj světla

Zdroj světla:	Pulsed infrared laser diode
Vlnová délka:	940 nm
Třída laseru:	1

Elektrické parametry

Doba odezvy:	< 25 ms (High Speed Mode) < 50 ms (Standard Mode) < 200 ms (High Accuracy Mode)
Rozsah napájecího napětí +Vs:	12 - 30 VDC
Maximální spotřeba proudu (bez zátěže):	45 mA (@ 12 VDC)
Běžná spotřeba proudu:	25 mA (@ 24 VDC)
Pokles napětí Vd:	<2.5 VDC
Výstupní obvod:	Analog 0 ... 10 VDC Push-pull / IO-Link
Výstupní signál:	0 ... 10 VDC
Výstupní proud:	100 mA (push-pull)
spínací výstup:	Light operate, switchable
Ochrana proti zkratu:	Yes
Ochrana proti přepólování:	Yes, Vs to GND

Komunikační rozhraní

Rozhraní:	IO-Link V1.1.4
IO-Link připojení:	Class A
Modulační rychlost (baud rate):	230.4 kBaud (COM 3)
Čas cyklu:	≥ 0.7 ms
Procesní data:	48 Bit
Struktura procesních dat:	Bit 0 = SSC1.1 (distance) Bit 1 = SSC1.2 (distance) Bit 2 = Uncertainty Flag Bit 3 = alarm Bit 8-15 = scale factor Bit 16-47 = 32 Bit measurement
Nastavitelné parametry:	Switching point Operation mode Time filters Locater function Output logic Teach-in mode Analog output characteristic LED status indicators Deactivate the sensor element
Další údaje:	Distance Excess gain Device temperature

Mechanické parametry

Šířka \| průměr:	11 mm
Výška \| Délka:	32 mm
Hloubka:	21 mm
Konstrukce:	Rectangular
Mechanické upevnění:	Sleeve smooth (brass)
Materiál pouzdra:	Plastic (ABS, ASA, PMMA)
Materiál krycího skla:	PMMA
Způsoby připojení:	Connector M8 4 pin

Okolní podmínky

Třída krytí:	IP 67
Pracovní teplota:	-30 - +55 °C
Skladovací teplota:	-40 - +70 °C
odolnost vůči vibracím:	IEC 60068-2-6:2008 10 g at f = 10 - 2000 Hz, duration 150 min per axis
Odolnost vůči nárazu:	IEC 60068-2-27:2009 50 g / 11 ms resp. 100 g / 6 ms, 10 jolts per axis and direction
