O300.GP-GW1J.72N - Diffuse sensors with background suppression - miniature

O300.GP-GW1J.72N - Diffuse sensors with background suppression - miniature
  • background suppression
  • 30 … 200 mm
  • pulsed PinPoint LED
  • push-pull
  • Teach-in and IO-Link
  • connector M8 4 pin
  • -25 … 60 °C
  • IP 67
Objednací číslo: 11125023
Výrobce: Baumer Electric AG
Dostupnost: 3 ks (zobrazit skladovou dostupnost)

Můžete mít ihned. Možnost osobního odběru v pracovní dny od 8:00 do 16:00 na adrese firmy po předchozí telefonické dohodě.
Zboží odesíláme okamžitě. Zboží, které závazně objednáte v pracovních dnech do 11:00 hodin, vám odešleme ještě tentýž den.
+Přidat do nezávazné poptávky

Poradím vám

Ing. Jaroslav Dančák
Ing. Jaroslav Dančák
Technik specialista pro průmyslové snímače
BAUMER
Ing. Jaroslav Dančák - QR Kontakt
+420 733 533 400
jaroslav.dancak@ajptech.cz
Parametry
Nákresy
Diagramy
Ke stažení
Příslušenství
Podpora
Podobné produkty

Parametry

Základní parametry

Typ: Background suppression
Snímací vzdálenost: 30 - 200 mm
Snímací rozsah: 15 - 200 mm
Indikace napájení: LED green
Světelný indikátor: LED yellow
Natavení vzdálenosti snímáni: Teach-in and IO-Link
Potlačení vzájemného ovlivňování: Yes
Odklon od osy: < 2°

Zdroj světla

Zdroj světla: Pulsed PinPoint LED
Vlnová délka: 630 nm

Elektrické parametry

Doba odezvy: < 0.49 ms
Rozsah napájecího napětí +Vs: 10 - 30 VDC
Maximální spotřeba proudu (bez zátěže): 45 mA
Běžná spotřeba proudu: 30 mA
Pokles napětí Vd: <3 VDC
Výstupní funkce: Light / dark operate
Výstupní obvod: Push-pull
Výstupní proud: 100 mA
Ochrana proti zkratu: Yes
Ochrana proti přepólování: Yes

Mechanické parametry

Šířka | průměr: 12.9 mm
Výška | Délka: 32.3 mm
Hloubka: 23 mm
Konstrukce: Rectangular
Materiál pouzdra: Plastic (ASA, PMMA)
Materiál krycího skla: PMMA
Způsoby připojení: Connector M8 4 pin

Okolní podmínky

Třída krytí: IP 67
Pracovní teplota: -25 - +60 °C
