OT330.GN-NLNVT.72N

2.5 m sensing range thanks to time of flight principle
Reliable also on very dark and shiny objects
Manipulation-proof, simple teach-in via qTeach
Infrared laser light source suitable for use in dusty or smoky environments
Alignment Guide - visible, red light beam for aligning the infrared laser

Objednací číslo: 11731315
Výrobce: Baumer Electric AG

Dostupnost: na dotaz

+Přidat do nezávazné poptávky

Parametry

Nákresy

Diagramy

Ke stažení

Příslušenství

Podpora

Podobné produkty

Parametry

Základní parametry

Typ:	Background suppression
Verze:	Time of Flight
Snímací vzdálenost:	0 - 2500 mm
Snímací rozsah:	0 - 2625 mm
Opakovatelnost:	< 2 - 1.5 mm
Teplotní drift:	<0,3 mm/K: <750 mm <0,04 % Sde/K: >750 mm
Indikace napájení:	LED green
Výstupní indikátor:	LED yellow
Natavení vzdálenosti snímáni:	qTeach
Potlačení vzájemného ovlivňování:	Yes
Typ paprsku:	Point
Odklon od osy:	< 1,5°

Zdroj světla

Zdroj světla:	Pulsed infrared laser diode
Třída laseru:	1
Vlnová délka:	940 nm

Elektrické parametry

Doba odezvy:	< 50 ms (Standard Mode)
Rozsah napájecího napětí +Vs:	10 - 30 VDC
Maximální spotřeba proudu (bez zátěže):	55 mA (@ 10 VDC)
Běžná spotřeba proudu:	25 mA (@ 24 VDC)
Pokles napětí Vd:	<2.5 VDC
Výstupní funkce:	Light operate, switchable
Výstupní obvod:	NPN complementary
Výstupní proud:	100 mA
Ochrana proti zkratu:	Yes
Ochrana proti přepólování:	Yes

Mechanické parametry

Šířka \| průměr:	11 mm
Výška \| Délka:	32 mm
Hloubka:	21 mm
Konstrukce:	Rectangular
Mechanické upevnění:	Sleeve smooth (brass)
Materiál pouzdra:	Plastic (ABS, ASA, PMMA)
Materiál krycího skla:	PMMA
Způsoby připojení:	Connector M8 4 pin

Okolní podmínky

Třída krytí:	IP 67
Pracovní teplota:	-30 - +55 °C
Skladovací teplota:	-40 - +70 °C
odolnost vůči vibracím:	IEC 60068-2-6:2008 10 g at f = 10 - 2000 Hz, duration 150 min per axis
Odolnost vůči nárazu:	IEC 60068-2-27:2009 50 g / 11 ms resp. 100 g / 6 ms, 10 jolts per axis and direction

Příslušenství

Obsahuje:Montážní příslušenství Kabely s volným koncem LED-Kabely s volným koncem Kabely

Montážní příslušenství

Další podobné produkty naleznete v kategorii: Montážní příslušenství

Produkt (12) / Popis	Produktová skupina	Skladová dostupnost
Mounting base Material: Plastic (PA) Part of an assembly	Montážní příslušenství	1 ks
Mounting bracket O300 - Retrofit for sensors series 20 - Mounting bracket O300 - Retrofit for sensors series 20 Material: Steel	Montážní příslušenství	na dotaz
Mounting bracket O300/U300 (L design) - Mounting bracket O300/U300 (L design) Material: Steel	Montážní příslušenství	na dotaz
Mounting plate series 300 and ø12 mm Material: Steel Part of an assembly	Montážní příslušenství	na dotaz
Mounting rod 200 mm Material: Aluminium Part of an assembly Different lengths available	Montážní příslušenství	na dotaz
Mounting rod 250 mm Material: Aluminium Part of an assembly Different lengths available	Montážní příslušenství	2 ks
Mounting rod 300 mm Material: Aluminium Part of an assembly Different lengths available	Montážní příslušenství	3 ks
Mounting rod with mounting plate holder 200 mm Material: Aluminium Part of an assembly Different lengths available	Montážní příslušenství	na dotaz
Mounting rod with mounting plate holder 250 mm Material: Aluminium Part of an assembly Different lengths available	Montážní příslušenství	na dotaz
Mounting rod with mounting plate holder 300 mm Material: Aluminium Part of an assembly Different lengths available	Montážní příslušenství	1 ks
Sensofix O300/U300 - Sensofix O300/U300 Clamps made of stainless steel Ball pivots made of galvanized steel Mounting panel made of stainless steel	Montážní příslušenství	4 ks
Two-way connector Material: Plastic (PA) Part of an assembly	Montážní příslušenství	5 ks

Kabely s volným koncem

Další podobné produkty naleznete v kategorii: Kabely a konektory

Produkt (28) / Popis	Délka kabelu	Skladová dostupnost
CAM8.A4-11232537 M8, female, A-coded; 4-poles; PUR, 100 cm, free cable end Dragchain capable Head A: IP65, IP66K, IP67 Cable: good resistance against flames and oils Halogen free	1 m	na dotaz
CAM8.A4-11232538 M8, female, A-coded; 4-poles; PUR, 200 cm, free cable end Dragchain capable Head A: IP65, IP66K, IP67 Cable: good resistance against flames and oils Halogen free	2 m	2 ks
CAM8.A4-11232539 M8, female, A-coded; 4-poles; PUR, 300 cm, free cable end Dragchain capable Head A: IP65, IP66K, IP67 Cable: good resistance against flames and oils Halogen free	3 m	na dotaz
CAM8.A4-11232540 M8, female, A-coded; 4-poles; PUR, 500 cm, free cable end Dragchain capable Head A: IP65, IP66K, IP67 Cable: good resistance against flames and oils Halogen free	5 m	na dotaz
CAM8.A4-11232541 M8, female, A-coded; 4-poles; PUR, 1000 cm, free cable end Dragchain capable Head A: IP65, IP66K, IP67 Cable: good resistance against flames and oils Halogen free	10 m	2 ks
CAM8.A4-11232542 M8, female, A-coded; 4-poles; PUR, 1500 cm, free cable end Dragchain capable Head A: IP65, IP66K, IP67 Cable: good resistance against flames and oils Halogen free	15 m	na dotaz
CAM8.A4-11232543 M8, female, A-coded; 4-poles; PUR, 2000 cm, free cable end Dragchain capable Head A: IP65, IP66K, IP67 Cable: good resistance against flames and oils Halogen free	20 m	na dotaz
CAM8.A4-11232545 M8, female, A-coded; 4-poles; PUR, 100 cm, free cable end Dragchain capable Head A: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames and oils Halogen free	1 m	na dotaz
CAM8.A4-11232546 M8, female, A-coded; 4-poles; PUR, 200 cm, free cable end Dragchain capable Head A: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames and oils Halogen free	2 m	na dotaz
CAM8.A4-11232547 M8, female, A-coded; 4-poles; PUR, 300 cm, free cable end Dragchain capable Head A: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames and oils Halogen free	3 m	na dotaz
CAM8.A4-11232548 M8, female, A-coded; 4-poles; PUR, 500 cm, free cable end Dragchain capable Head A: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames and oils Halogen free	5 m	> 15 ks
CAM8.A4-11232549 M8, female, A-coded; 4-poles; PUR, 1000 cm, free cable end Dragchain capable Head A: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames and oils Halogen free	10 m	na dotaz
CAM8.A4-11232550 M8, female, A-coded; 4-poles; PUR, 1500 cm, free cable end Dragchain capable Head A: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames and oils Halogen free	15 m	na dotaz
CAM8.A4-11232551 M8, female, A-coded; 4-poles; PUR, 2000 cm, free cable end Dragchain capable Head A: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames and oils Halogen free	20 m	na dotaz
CAM8.A4-11232562 M8, female, A-coded; 4-poles; PUR, 100 cm, shielded, free cable end Dragchain capable Head A: IP65, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	1 m	na dotaz
CAM8.A4-11232563 M8, female, A-coded; 4-poles; PUR, 200 cm, shielded, free cable end Dragchain capable Head A: IP65, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	2 m	na dotaz
CAM8.A4-11232564 M8, female, A-coded; 4-poles; PUR, 300 cm, shielded, free cable end Dragchain capable Head A: IP65, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	3 m	na dotaz
CAM8.A4-11232565 M8, female, A-coded; 4-poles; PUR, 500 cm, shielded, free cable end Dragchain capable Head A: IP65, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	5 m	3 ks
CAM8.A4-11232566 M8, female, A-coded; 4-poles; PUR, 1000 cm, shielded, free cable end Dragchain capable Head A: IP65, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	10 m	na dotaz
CAM8.A4-11232567 M8, female, A-coded; 4-poles; PUR, 1500 cm, shielded, free cable end Dragchain capable Head A: IP65, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	15 m	na dotaz
CAM8.A4-11232568 M8, female, A-coded; 4-poles; PUR, 2000 cm, shielded, free cable end Dragchain capable Head A: IP65, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	20 m	na dotaz
CAM8.A4-11232570 M8, female, A-coded; 4-poles; PUR, shielded, 100 cm, free cable end Dragchain capable Head A: IP65, IP67 Cable: good resistance against chemicals, flames and oils Halogen free	1 m	na dotaz
CAM8.A4-11232571 M8, female, A-coded; 4-poles; PUR, shielded, 200 cm, free cable end Dragchain capable Head A: IP65, IP67 Cable: good resistance against chemicals, flames and oils Halogen free	2 m	na dotaz
CAM8.A4-11232572 M8, female, A-coded; 4-poles; PUR, shielded, 300 cm, free cable end Dragchain capable Head A: IP65, IP67 Cable: good resistance against chemicals, flames and oils Halogen free	3 m	na dotaz
CAM8.A4-11232573 M8, female, A-coded; 4-poles; PUR, shielded, 500 cm, free cable end Dragchain capable Head A: IP65, IP67 Cable: good resistance against chemicals, flames and oils Halogen free	5 m	na dotaz
CAM8.A4-11232574 M8, female, A-coded; 4-poles; PUR, shielded, 1000 cm, free cable end Dragchain capable Head A: IP65, IP67 Cable: good resistance against chemicals, flames and oils Halogen free	10 m	na dotaz
CAM8.A4-11232575 M8, female, A-coded; 4-poles; PUR, shielded, 1500 cm, free cable end Dragchain capable Head A: IP65, IP67 Cable: good resistance against chemicals, flames and oils Halogen free	15 m	na dotaz
CAM8.A4-11232576 M8, female, A-coded; 4-poles; PUR, shielded, 2000 cm, free cable end Dragchain capable Head A: IP65, IP67 Cable: good resistance against chemicals, flames and oils Halogen free	20 m	na dotaz

LED-Kabely s volným koncem

Další podobné produkty naleznete v kategorii: Kabely a konektory

Produkt (7) / Popis	Délka kabelu	Skladová dostupnost
CAM8.A4-11232553 M8, female, A-coded; 4-poles; PUR, 100 cm, free cable end Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils	1 m	na dotaz
CAM8.A4-11232554 M8, female, A-coded; 4-poles; PUR, 200 cm, free cable end Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils	2 m	na dotaz
CAM8.A4-11232555 M8, female, A-coded; 4-poles; PUR, 300 cm, free cable end Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils	3 m	na dotaz
CAM8.A4-11232556 M8, female, A-coded; 4-poles; PUR, 500 cm, free cable end Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils	5 m	na dotaz
CAM8.A4-11232557 M8, female, A-coded; 4-poles; PUR, 1000 cm, free cable end Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils	10 m	na dotaz
CAM8.A4-11232558 M8, female, A-coded; 4-poles; PUR, 1500 cm, free cable end Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils	15 m	na dotaz
CAM8.A4-11232559 M8, female, A-coded; 4-poles; PUR, 2000 cm, free cable end Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils	20 m	na dotaz

Kabely

Další podobné produkty naleznete v kategorii: Kabely a konektory

Produkt (41) / Popis	Délka kabelu	Skladová dostupnost
CAM12.A3-11230431 M12, male, A-coded, 3-poles; PUR, 500 cm; M8, female, A-coded, 3-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	5 m	na dotaz
CAM12.A3-11230871 M12, male, A-coded, 3-poles; PUR, 100 cm; M8, female, A-coded, 3-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	1 m	na dotaz
CAM12.A3-11230872 M12, male, A-coded, 3-poles; PUR, 200 cm; M8, female, A-coded, 3-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	2 m	na dotaz
CAM12.A3-11230873 M12, male, A-coded, 3-poles; PUR, 300 cm; M8, female, A-coded, 3-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	3 m	na dotaz
CAM12.A3-11230874 M12, male, A-coded, 3-poles; PUR, 1000 cm; M8, female, A-coded, 3-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	10 m	na dotaz
CAM12.A3-11232969 M12, male, A-coded, 3-poles; PUR, 1500 cm; M8, female, A-coded, 3-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	15 m	na dotaz
CAM12.A3-11232970 M12, male, A-coded, 3-poles; PUR, 2000 cm; M8, female, A-coded, 3-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	20 m	na dotaz
CAM12.A4-11230429 M12, male, A-coded, 4-poles; PUR, 100 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	1 m	na dotaz
CAM12.A4-11230430 M12, male, A-coded, 4-poles; PUR, 500 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	5 m	na dotaz
CAM12.A4-11230432 M12, male, A-coded, 4-poles; PUR, 100 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	1 m	na dotaz
CAM12.A4-11230433 M12, male, A-coded, 4-poles; PUR, 500 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	5 m	na dotaz
CAM12.A4-11230949 M12, male, A-coded, 4-poles; PUR, 200 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	2 m	2 ks
CAM12.A4-11230950 M12, male, A-coded, 4-poles; PUR, 300 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	3 m	na dotaz
CAM12.A4-11230951 M12, male, A-coded, 4-poles; PUR, 1000 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	10 m	na dotaz
CAM12.A4-11230952 M12, male, A-coded, 4-poles; PUR, 200 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	2 m	3 ks
CAM12.A4-11230953 M12, male, A-coded, 4-poles; PUR, 1000 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	10 m	na dotaz
CAM12.A4-11230954 M12, male, A-coded, 4-poles; PUR, 200 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils	2 m	na dotaz
CAM12.A4-11232952 M12, male, A-coded, 4-poles; PUR, 2000 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	20 m	na dotaz
CAM12.A4-11232955 M12, male, A-coded, 4-poles; PUR, 1500 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	15 m	na dotaz
CAM12.A4-11232956 M12, male, A-coded, 4-poles; PUR, 2000 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	20 m	na dotaz
CAM8.A3-11230371 M8, male, A-coded, 3-poles; PUR, 100 cm; M8, female, A-coded, 3-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	1 m	na dotaz
CAM8.A3-11230372 M8, male, A-coded, 3-poles; PUR, 250 cm; M8, female, A-coded, 3-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	2,5 m	na dotaz
CAM8.A3-11230373 M8, male, A-coded, 3-poles; PUR, 500 cm; M8, female, A-coded, 3-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	5 m	na dotaz
CAM8.A3-11230509 M8, male, A-coded, 3-poles; PUR, 500 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	5 m	na dotaz
CAM8.A3-11230514 M8, male, A-coded, 3-poles; PUR, 100 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	1 m	na dotaz
CAM8.A3-11230515 M8, male, A-coded, 3-poles; PUR, 500 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	5 m	na dotaz
CAM8.A3-11231058 M8, male, A-coded, 3-poles; PUR, 200 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	2 m	na dotaz
CAM8.A3-11231059 M8, male, A-coded, 3-poles; PUR, 1000 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	10 m	na dotaz
CAM8.A3-11231063 M8, male, A-coded, 3-poles; PUR, 200 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	2 m	na dotaz
CAM8.A3-11231064 M8, male, A-coded, 3-poles; PUR, 1000 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	10 m	na dotaz
CAM8.A3-11233223 M8, male, A-coded, 3-poles; PUR, 300 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	3 m	na dotaz
CAM8.A3-11233224 M8, male, A-coded, 3-poles; PUR, 1500 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	15 m	na dotaz
CAM8.A3-11233225 M8, male, A-coded, 3-poles; PUR, 2000 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	20 m	na dotaz
CAM8.A3-11233227 M8, male, A-coded, 3-poles; PUR, 100 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	1 m	na dotaz
CAM8.A3-11233228 M8, male, A-coded, 3-poles; PUR, 300 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	3 m	na dotaz
CAM8.A3-11233229 M8, male, A-coded, 3-poles; PUR, 1500 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	15 m	na dotaz
CAM8.A3-11233230 M8, male, A-coded, 3-poles; PUR, 2000 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	20 m	na dotaz
CAM8.A4-11230374 M8, male, A-coded, 4-poles; PUR, 100 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	1 m	na dotaz
CAM8.A4-11230375 M8, male, A-coded, 4-poles; PUR, 200 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	2 m	na dotaz
CAM8.A4-11230519 M8, male, A-coded, 4-poles; PUR, 500 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	5 m	na dotaz
CAM8.A4-11233221 M8, male, A-coded, 4-poles; PUR, 2000 cm; M8, female, A-coded, 4-poles Dragchain capable; suitable for robotics ± 180 °/m Head A: IP65, IP66K, IP67; Head B: IP65, IP66K, IP67 Cable: good resistance against chemicals, flames, oils Halogen free	20 m	na dotaz
