IHRM 12P1501 - Hall sensors

IHRM 12P1501 - Hall sensors
  • cable FEP, 2 m
  • -40 … 120 °C
Objednací číslo: 10123731
Výrobce: Baumer Electric AG
Dostupnost: na dotaz



Chcete znát dostupnost zboží? Vložte produkt do poptávky a my se vám ozveme.
Potřebujete poradit s výběrem nebo najít alternativu? Kontaktujte produktového specialistu.

+Přidat do nezávazné poptávky

Poradím vám

Ondřej Štěpánek
Ondřej Štěpánek
Produktový manažer
BAUMER
Ondřej Štěpánek - QR Kontakt
+420 733 101 651
ondrej.stepanek@ajptech.cz
Parametry
Nákresy
Ke stažení
Příslušenství
Podpora
Podobné produkty

Parametry

Základní parametry

Verze: Full metal
Typ snímače: Differential hall sensors
Maximální snímací vzdálenost: <1 mm (module 1), <2.5 mm (module 3)
Modul zubu: > module 1
Šířka zubu: > 6 mm
Materiál snímací plochy: Ferromagnetic

Elektrické parametry

Rozsah spínací frekvence: 1 - 20 kHz
Rozsah napájecího napětí +Vs: 8 - 28 VDC
Maximální spotřeba proudu (bez zátěže): 20 mA
Výstup A: PNP
Výstup B: None
Výstupní proud: 30 mA
Pokles napětí Vd: <3 VDC
Ochrana proti zkratu: Yes
Ochrana proti přepólování: Yes, Vs to GND

Mechanické parametry

Konstrukce: Cylindrical threaded
Materiál pouzdra: Stainless steel
Rozměry: 12 mm
Délka pouzdra: 60 mm
Způsob instalace: Keyway
Způsoby připojení: Cable FEP, 2 m
Tlaková odolnost aktivní části snímače: 20 bar

Okolní podmínky

Pracovní teplota: -40 - +120 °C
Třída krytí(snímací část): IP 68
Třída krytí(pouzdro): IP 67
