| 10-GigE DA Cable Copper SFP+/SFP+, 5.0m - Copper cable for 10-GigE connection
- SFP+ module to SFP+ module (direct attached)
- length 5.0 m
- Cisco Coding
| na dotaz |
| Adapter Cable TX to VCXG VCXU- Adapter to connect VCXG and VCXU cameras to existing TXG cabling
- Split cable M8/8-pin female connector to 1x M8/3-pin male connector (power) and 1x M8/4-pin male connector (I/Os)
- Protection class IP65/IP67
- Length 0.4 m
| na dotaz |
| Adapter Cable TX to VCXG.I VLXT- Adapter to connect VCXG.I or VLXT cameras to existing TXG cabling
- Split cable M12/12-pin male connector to 1x M8/3-pin female connector (power) and 1x M8/4-pin female connector (I/Os)
- Protection class IP65/IP67
- Length 0.4 m
| na dotaz |
| Cable GigE M12/RJ45, 5,0 m, chain- Gigabit Ethernet interface cable
- for TXG-I7 cameras
- CAT6
- M12 (screw lock) to RJ45
- cable carrier compatible
- length 5,0 m
| na dotaz |
| Cable GigE M12X/RJ45, STP 10.0m, flex- Gigabit Ethernet interface cable
- CAT6A
- M12/8-pin connector, X-coded (screw lock) to RJ45
- cable carrier compatible
- length 10,0 m
| 2 ks |
| Cable GigE M12X/RJ45, STP 15.0m, flex- Gigabit Ethernet interface cable
- CAT6A
- M12/8-pin connector, X-coded (screw lock) to RJ45
- cable carrier compatible
- length 15,0 m
| na dotaz |
| Cable GigE M12X/RJ45, STP 2.0m, flex- Gigabit Ethernet interface cable
- CAT6A
- M12/8-pin connector, X-coded (screw lock) to RJ45
- cable carrier compatible
- length 2,0 m
| na dotaz |
| Cable GigE M12X/RJ45, STP 20.0m, flex- Gigabit Ethernet interface cable
- CAT6A
- M12/8-pin connector, X-coded (screw lock) to RJ45
- cable carrier compatible
- length 20,0 m
| na dotaz |
| Cable GigE M12X/RJ45, STP 30.0m, flex- Gigabit Ethernet interface cable
- CAT6A
- M12/8-pin connector, X-coded (screw lock) to RJ45
- cable carrier compatible
- length 30,0 m
| na dotaz |
| Cable GigE M12X/RJ45, STP 5.0m, flex- Gigabit Ethernet interface cable
- CAT6A
- M12/8-pin connector, X-coded (screw lock) to RJ45
- cable carrier compatible
- length 5,0 m
| 1 ks |
| Cable GigE M12X/RJ45, STP, 10.0m, flex, 90°- Gigabit Ethernet interface cable
- CAT6A
- M12/8-pin connector, X-coded (screw lock), 90° angled to RJ45
- cable carrier compatible
- suitable for robotic applications (+/- 180°/ 0.5 m, min. 1.000.000 torsion cycles)
- length 10,0 m
| na dotaz |
| Cable GigE M12X/RJ45, STP, 2.0m, flex, 90°- Gigabit Ethernet interface cable
- CAT6A
- M12/8-pin connector, X-coded (screw lock), 90° angled to RJ45
- cable carrier compatible
- suitable for robotic apllications (+/- 180°/0,5m, min. 1.000.000 torsion cycles)
- length 2,0 m
| na dotaz |
| Cable GigE M12X/RJ45, STP, 20.0m, flex, 90°- Gigabit Ethernet interface cable
- CAT6A
- M12/8-pin connector, X-coded (screw lock), 90° angled to RJ45
- cable carrier compatible
- suitable for robotic applications (+/- 180°/ 0.5 m, min. 1.000.000 torsion cycles)
- length 20,0 m
| na dotaz |
| Cable GigE M12X/RJ45, STP, 30.0m, flex, 90°- Gigabit Ethernet interface cable
- CAT6A
- M12/8-pin connector, X-coded (screw lock), 90° angled to RJ45
- cable carrier compatible
- suitable for robotic applications (+/- 180°/ 0.5 m, min. 1.000.000 torsion cycles)
- length 30,0 m
| na dotaz |
| Cable GigE M12X/RJ45, STP, 5.0m, flex, 90°- Gigabit Ethernet interface cable
- CAT6A
- M12/8-pin connector, X-coded (screw lock), 90° angled to RJ45
- cable carrier compatible
- suitable for robotic applications (+/- 180°/ 0.5 m, min. 1.000.000 torsion cycles)
- length 5,0 m
| na dotaz |
| Cable GigE RJ45/RJ45, 3,0 m- Gigabit Ethernet interface cable
- CAT7
- length 3,0 m
| na dotaz |
| Cable GigE RJ45/RJ45, 6,0 m- Gigabit Ethernet interface cable
- CAT7
- length 6,0 m
| na dotaz |
| Cable GigE RJ45s/RJ45, 10,0 m, flex v2- Gigabit Ethernet interface cable
- CAT5e
- RJ45 (screw lock) to RJ45
- suitable for cable carrier and torsion applications
- length 10,0 m
| na dotaz |
| Cable GigE RJ45s/RJ45, 20,0 m, flex v2- Gigabit Ethernet interface cable
- CAT5e
- RJ45 (screw lock) to RJ45
- suitable for cable carrier and torsion applications
- length 20,0 m
| na dotaz |
| Cable GigE RJ45s/RJ45, 30,0 m, flex v2- Gigabit Ethernet interface cable
- CAT5e
- RJ45 (screw lock) to RJ45
- suitable for cable carrier and torsion applications
- length 30,0 m
| na dotaz |
| Cable IEEE1394b/a, 2,5 m screw lock- FireWire® interface cable
- IEEE1394b connector (screw lock) to IEEE1394a
- length 2,5 m
| na dotaz |
| Cable Mini CL SDR/SDR 5,0 m- Camera Link® interface cable
- SDR to SDR connector
- length 5,0 m
- up to 80MHz pixel clock
| na dotaz |
| Cable Power Adapter M12/DC Connector- shielded adapter connection cable
- M12/12-pin male connector to confectioned DC connector
- length 2,0 m
- manufactured cable: 11201118 ESG 34JP0200GS
| 2 ks |
| ESG 34JP0200GS- shielded process interface cable
- M12/12-pin female connector to open wires
- cable carrier compatible
- suitable for robotic applications (+/- 180°/m, min. 500.000 torsion cycles)
- length 2,0 m
| na dotaz |
| ESG 34JP0500GS- shielded process interface cable
- M12/12-pin female connector to open wires
- cable carrier compatible
- suitable for robotic applications (+/- 180°/m, min. 500.000 torsion cycles)
- length 5,0 m
| 1 ks |
| ESG 34JP1000GS- shielded process interface cable
- M12/12-pin female connector to open wires
- cable carrier compatible
- suitable for robotic applications (+/- 180°/m, min. 500.000 torsion cycles)
- length 10,0 m
| 2 ks |
| ESG 34JP2000GS- shielded process interface cable
- M12/12-pin female connector to open wires
- cable carrier compatible
- suitable for robotic applications (+/- 180°/m, min. 500.000 torsion cycles)
- length 20,0 m
| na dotaz |
| ESW 33JP0200GS- shielded process interface cable
- 90° angled M12/12-pin female connector to open wires
- cable carrier compatible
- suitable for robotic applications (+/- 180°/m, min. 500.000 torsion cycles)
- length 2,0 m
| na dotaz |
| ESW 33JP0500GS- shielded process interface cable
- 90° angled M12/12-pin female connector to open wires
- cable carrier compatible
- suitable for robotic applications (+/- 180°/m, min. 500.000 torsion cycles)
- length 5,0 m
| na dotaz |
| ESW 33JP1000GS- shielded process interface cable
- 90° angled M12/12-pin female connector to open wires
- cable carrier compatible
- suitable for robotic applications (+/- 180°/m, min. 500.000 torsion cycles)
- length 10,0 m
| na dotaz |
| ESW 33JP2000GS- shielded process interface cable
- 90° angled M12/12-pin female connector to open wires
- cable carrier compatible
- suitable for robotic applications (+/- 180°/m, min. 500.000 torsion cycles)
- length 20,0 m
| na dotaz |
| Fiber Optical Cable SFP+/SFP+, 10,0 m - Fiber Optical cable for 10-GigE connection
- SFP+ module to SFP+ module (direct attached)
- length 10.0 m
- Juniper Coding
| na dotaz |
| Fiber Optical Cable SFP+/SFP+, 10,0 m, flex - Fiber Optical cable for 10-GigE connection
- SFP+ module to SFP+ module (direct attached)
- cable carrier compatible
- suitable for robotic applications
- length 10.0 m
- Juniper Coding
| na dotaz |
| Fiber Optical Cable XSsh/LC, IP67, 20,0m - Fiber Optical cable for 10-GigE connection, multi mode
- SFP+ module to SFP+ module (SFP+ modules are not included and have to be ordered separately)
- high robustness - crush resistance 2100 N/cm
- length 20.0m
- IP65/67 in combination with “Housing Cable Adapter SFP+/IP67”
| na dotaz |
| Housing Cable Adapter SFP+/IP67 - Housing adapter for VLXT.FO cameras
- use in combination with Harting fiber optical cable IP67 (11213911) to reach IP 65/67 protection class
| na dotaz |
| Kabel GigE RJ45s/RJ45, 10,0 m, chain- Gigabit Ethernet interface cable
- CAT6
- RJ45 (screw lock) to RJ45
- cable carrier compatible
- length 10,0 m
| 1 ks |
| Kabel GigE RJ45s/RJ45, 15,0 m, chain- Gigabit Ethernet interface cable
- CAT6
- RJ45 (screw lock) to RJ45
- cable carrier compatible
- length 15,0 m
| na dotaz |
| Kabel GigE RJ45s/RJ45, 20,0 m, chain- Gigabit Ethernet interface cable
- CAT6
- RJ45 (screw lock) to RJ45
- cable carrier compatible
- length 20,0 m
| na dotaz |
| Kabel GigE RJ45s/RJ45, 5,0 m, chain- Gigabit Ethernet interface cable
- CAT6
- RJ45 (screw lock) to RJ45
- cable carrier compatible
- length 5,0 m
| na dotaz |
| KSG 34A/KSG45AR0200G/E- M12, male;, D-coded, 4-poles PUR, 200 cm, shielded; RJ45, male, A-coded, 4-poles
- Suitable for robotics ± 180 °/m
- Head A: IP67; Head B: IP20
- Cable: good resistance against flames, oils
| na dotaz |
| KSG 34A/KSG45AR0500G/E- M12, male, D-coded, 4-poles; PUR, 500 cm, shielded; RJ45, male, 4-poles
- Suitable for robotics ± 180 °/m
- Head A: IP67; Head B: IP20
- Cable: good resistance against flames, oils
| 9 ks |
| KSG 34A/KSG45AR1000G/E- M12, male, D-coded, 4-poles; PUR, 1000 cm, shielded; RJ45, male, 4-poles
- Suitable for robotics ± 180 °/m
- Head A: IP67; Head B: IP20
- Cable: good resistance against flames, oils
| na dotaz |
| KSG U2/KSGU6GC0300G- USB 3.0 interface cable
- screw lock Micro-B connector to type A (optional screw lock) connector, both connectors with die-cast housing
- length 3.0 m
| na dotaz |
| KSG U2/KSGU6GC0500G- USB 3.0 interface cable
- screw lock Micro-B connector to type A (optional screw lock) connector, both connectors with die-cast housing
- length 5.0 m
| 1 ks |
| MX Flexprint 200 mm- flexprint to connect system and sensor print of cameras of the MX series
- length 20 cm
| na dotaz |
| Shielded cable 3 wires, 10,0 m- shielded power cable
- M8/3-pin female connector to open wires
- cable carrier compatible
- length 10,0 m
| na dotaz |
| Shielded cable 4 wires, 10,0 m- shielded process interface cable (trigger and flash)
- M8/4-pin female connector to open wires
- cable carrier compatible
- length 10,0 m
| na dotaz |
| Shielded cable 4 wires, 5,0 m- shielded process interface cable (trigger and flash)
- M8/4-pin female connector to open wires
- cable carrier compatible
- length 5,0 m
| na dotaz |
| Z-ESG 32DH0500G- shielded process interface and power cable for Baumer VisiLine® cameras
- M8/6-pin female connector to open wires
- cable carrier compatible
- length 5,0 m
| na dotaz |
| Z-ESG 32DH1000G- shielded process interface and power cable for Baumer VisiLine® cameras
- M8/6-pin female connector to open wires
- cable carrier compatible
- length 10,0 m
| na dotaz |
