Shielded cable 4 wires, 10,0 m

shielded process interface cable (trigger and flash)
M8/4-pin female connector to open wires
cable carrier compatible
length 10,0 m

Objednací číslo: 11008778
Výrobce: Baumer Electric AG

Dostupnost: na dotaz

Chcete znát dostupnost zboží? Vložte produkt do poptávky a my se vám ozveme.
Potřebujete poradit s výběrem nebo najít alternativu? Kontaktujte produktového specialistu.

+Přidat do nezávazné poptávky

Poradím vám

Ing. Jakub Sedlmajer

Produktový specialista pro průmyslové čtečky a kamerové systémy
BAUMER | IOSS

+420 739 087 013

jakub.sedlmajer@ajptech.cz

Parametry

Diagramy

Ke stažení

Podpora

Podobné produkty

Parametry

Elektrické parametry

Stínění:	yes
Počet pinů konektoru:	4
Konektory:	M8 female connector, screw lock open wires

Mechanické parametry

nejmenší poloměr ohybu:	25 mm
instalace s nejmenším poloměrem ohybu:	63 mm
Počet ohybových cyklů:	250000
použitelné pro pohyblivé vedení:	yes
Délka kabelu [m]:	10 m
Hmotnost:	≤ 371 g
Materiál:	PUR

Rozhraní

Datové rozhraní:

Process interface

Podmínky prostředí

Ohnivzdornost:	DIN EN 60332-2-2 VDE 0482-332-2-2 IEC 60332-2-2 UL/CSA FT-2
Bez obsahu halogenů:	EN 50267-2-1 IEC 60754-1 VDE 0482-267-2-1
Třída krytí:	IP 67 (camera side)
