CAM8.A3-11230327

M8, female, A-coded, 3-poles; PUR, 500 cm, free cable end
Dragchain capable; suitable for robotics ± 180 °/m
Head A: IP65, IP66K, IP67
Cable: good resistance against chemicals, flames, oils
Halogen free

Objednací číslo: 11230327
Výrobce: Baumer Electric AG

Dostupnost: více než 15 ks (zobrazit skladovou dostupnost)

Můžete mít ihned. Možnost osobního odběru v pracovní dny od 8:00 do 16:00 na adrese firmy po předchozí telefonické dohodě.

Zboží odesíláme okamžitě. Zboží, které závazně objednáte v pracovních dnech do 11:00 hodin, vám odešleme ještě tentýž den.

+Přidat do nezávazné poptávky

Poradím vám

Ing. Jaroslav Dančák

Technik specialista pro průmyslové snímače
BAUMER

+420 733 533 400

jaroslav.dancak@ajptech.cz

Parametry

Nákresy

Ke stažení

Příslušenství

Podpora

Skladová dostupnost

Podobné produkty

Parametry

Strana A

Hlava A: Připojení:	M8
Hlava A: Úhlový vývod:	90°
Hlava A: Pohlaví:	Female
Hlava A: Kódování:	A
Hlava A: Počet pólů:	3
Hlava A: LED:	No
Hlava A: Šířka:	AF9
Hlava A: Utahovací moment:	0.4 Nm
Hlava A: Vroubkovaná matice:	Zinc-pressure die casting, surface Ni
Hlava A: Barva:	Black
Hlava A: Materiál těsnění:	FKM
Označovací strana A:	Yes

Strana B

Hlava B: Připojení:	Open-ended wires
Označovací strana B:	Yes

Kabely

Délka kabelu:	500 cm
Tolerance délky:	± 7.5 cm
Délka odizolování:	20 mm
Stíněný:	No
Struktura vodičů:	32 × 0.1 mm
AWG:	24
Vnější plášť: Materiál:	PUR
Vnější plášť: Barva:	Black
Průměr kabelu:	4.1 mm ± 5%
Průřez vodičů:	0.25 mm²

Kabel

Kabel: Rozsah teplot:	- 25 ...+ 80 °C
Kabel: teplotní rozsah:	- 40 ...+ 80 °C
Provozní napětí:	30 V AC/DC
Stíněný:	No
Ohýbací rádius (pevná instalace):	20.5 mm
Počet vodičů:	3
Počet a průměr vodičů:	3x0.25
Tolerance délky:	± 7.5 cm
Délka kabelu:	500 cm
Akcelerace:	max. 10 m/s²
AWG:	24
Ohýbací rádius (pevná instalace):	min. 5 × outer diameter
Torzní rychlost:	max. 35 cycles/min
Ohýbací rádius (pohyblivá instalace):	min. 10 × outer diameter
Typ kabelu:	3
Hmotnost kabelu:	approx. 26.4 g/m
Struktura vodičů:	32 × 0.1 mm
Průměr kabelu:	4.1 mm ± 5%
Vodič: Materiál:	Copper, bare
Vnější plášť: Materiál:	PUR
Izolace: Materiál:	PP
Počet ohybových cyklů (C drážka:	approx. 10000000 Cycles
Jmenovité napětí:	300 V
Počet torzních cyklů:	approx. 2000000 Cycles
Paired stranding:	No
Průměr jednoho vodiče:	0.1 mm
Kabel: Zkušební napětí:	2.5 kV
Torzní napětí v °:	± 180 °/m
Total stranding:	3 wires strand
Rychlost (C-drážka):	max. 3 m/s
Dráha projíždění (horizontálně):	max. 10 m
Průřez vodičů:	0.25 mm²
Zpracování vodičů:	No
Průměr vodiče včetně izolace:	1.25 mm ± 5%
Vnější plášť: Barva:	Black

Elektrické parametry

Pracovní napětí:	max. 50 V AC / 60 V DC
Provozní napětí:	30 V AC/DC
Jmenovité napětí:	300 V
Odpor kontaktů:	max. 30 mOhm
Provozní proud na kontakt:	max. 4 A

Mechanické parametry

Hlava A: Stupeň ochrany:	IP65, IP66K, IP67
Ohýbací rádius (pohyblivá instalace):	min. 10 × outer diameter
Ohýbací rádius (pevná instalace):	min. 5 × outer diameter
Počet ohybových cyklů (C drážka:	approx. 10000000 Cycles
Torzní rychlost:	max. 35 cycles/min
Torzní napětí v °:	± 180 °/m
Počet torzních cyklů:	approx. 2000000 Cycles
Akcelerace:	max. 10 m/s²
Rychlost (C-drážka):	max. 3 m/s

Podmínky prostředí

Rozsah teplot:	- 25 ...+ 80 °C
Rozsah teplot (fixní instalace):	- 25 ...+ 80 °C
Kabel: teplotní rozsah:	- 40 ...+ 80 °C
Možná pohyblivá instalace:	Yes
Hlava A: Chemická odolnost:	No
Hlava A: Ohňuvzdornost:	HB (UL 94)
Hlava A: Odolnost vůči olejům:	ASTM 1 oil, mineral oils, limited to hydraulic oils
Hlava A: odolnost vůči kyselinám:	No
Hlava A: Stupeň znečištění:	3
Kabel: Chemická odolnost:	Good (DIN EN 60811-404)
Kabel: ohňuvzdorný:	Conform UL 1581 §1090 (H), CSA FT2, IEC 60332-2-2
Kabel: odolnost vůči olejům:	Good (DIN EN 60811-404)
Kabel: bez silikonu:	Yes

Komerční data

Eclass:

27060311
